Kyocera AVX has released two new series of compact, thin-film band-pass filters engineered to deliver excellent RF performance in a range of high-power applications with crowded PCBs.
The BP1206 and BP2816 filters leverage the company’s proven, multilayer integrated thin-film (ITF) technology to deliver repeatable, reliable RF performance with low insertion loss, steep attenuation, sharp roll-off, low-noise and high temperature stability.
Both series enable quick, easy adjustment of RF parameters and feature ruggedly constructed compact, low-profile cases equipped with lead-free, solder-coated-nickel land grid array (LGA) terminations compatible with automated assembly processes, including reflow, wave, and vapor phase soldering.
Kyocera AVX’ technical services manager, Amir Kopelman, said: “These new high-power band-pass filters leverage our proven integrated thin-film technology and high-accuracy filter processing methods to meet the demands of high-frequency wireless applications extending throughout the telecommunications, military, aerospace, medical and consumer electronics industries.”
